ZumMesh 2322-40

High-bandwidth integrated graph-data self-organizing network data transmission radio

The ZumMesh 2322-40 employs a Software-Defined Radio (SDR) architecture to support its proprietary MESH ad-hoc networking protocol. This product boasts exceptional performance and supports intelligent frequency selection. By conducting real-time spectrum analysis across the entire network to assess the electronic environment, interference, and other factors at each node, it dynamically adjusts its operating frequency from a pre-set list, enabling intelligent dynamic transceiver frequency-division networking. This effectively avoids interference automatically and utilizes the exclusive STDM spatial channel multiplexing technology to enhance network efficiency by 50%.

The ZumMesh 2322-40 features dual transceiver RF channels, with a single channel capable of reaching 40dBm. Equipped with a 5dBi antenna, it achieves unobstructed bandwidths of 42Mbps@20KM, 28Mbps@50KM, 19Mbps@100KM, and 12Mbps@150KM.

How To Buy

Product Features

Supports STMD MESH intelligent self-organizing network technology, automatically selects the optimal path with roaming handover <10ms
Supports dual 40dBm output power (expandable to 41dBm)
Supports 1.25MHz, 2.5MHz, 5MHz, 10MHz, and 20MHz bandwidths
Supports 1.4G (1350~1450MHz)/655 (635-675)MHz/815 (800-830)MHz
Customizable from 0.7~2.7GHz
Supports up to 264 nodes
Supports intelligent frequency selection and automatic network-wide configuration.
Provides 2 network ports/2 RS232/1 3.3V TTL
Support for radio background scanning
